Diesel Self Start Silent Generator 5 KVA
Specification:
- Product Type: Diesel Generator
- Brand: HPM
- Maximum Output VA: 5000
- Rated AC. Output VA: 4200
- Rated Current Amps: 18.7
- NFB Amps: 19
- AC. Voltage On Laptop Mode: 230 Volts ± 10Volts,50 Hz, Single Phase
- AC.Voltage On Power Mode(No Load): 250 ± 5 Volts
- Alternator Max.Current Capacity: 32 Amps
- Alternator: Brushless, Rare Earth Magnetic Rotor, THD ? 2%, Pure Sine Wave Engine
- Engine Model: TP176F
- Type: Single Cylinder Air-cooled; 4-stroke, OHV, Direct Injection, Swiri Chamber, Inclined Type.
- Bore x Stroke: 76x68 mm
- Displacement: 308cc
- Starting System: Recoil Start / Self Start
- Fuel: Diesel
- Fuel Tank Capacity: 20 Liters
- Fuel Consumption Ltr./Hr.: 1.0 Ltr./hr.
- Lube. Oil Capacity: 900 ml.
- Lubricating Oil Consumption: 4.1 gm./Hr.
- Sound level(Db): <75DB
- Voltmeter: Digital
- Digital Hour Meter: Yes
- Oil Alert System: Yes
- Diesel Alert System: Yes
- Cooling Fan Indicator: Yes
- AMF Panel Auto & Remote Start Compatibility: Yes
- Fuel Level Guage: Yes
- Overload Protection(NFB): Yes
- Costar Wheels: Yes
- Dimension LxWxH (mm): 1195 x 525 x 710 mm
- Weight (Kgs.) Without Battery: 150 Kgs.
Special Note:
- Before the operation, be sure to add specified engine oil into the crankcase.
- What can run together?
- 1 Ton Air Conditioner - 1000W - 6 Can Run Together - Total Watt Usage = 1000 x 6 = 6000
- Computer/Ceiling Fan/ Television - 80w - 81 Can Run Together - Total Watt Usage = 80 x 81 = 6480
- Tube Light - 20W - 325 Can Run Together - Total Watt Usage = 20 x 325 = 6500
- Fridge/Refrigerator - 200W - 32 Can Run Together - Total Watt Usage = 200 x 32 = 6400
